* VDC-400 PCMCIA Data Controller - * LEGACY ITEM NO LONGER AVAILABLE |
| The VDC-400 Personal Data Controller is a type II PC Card (PCMCIA) card that complies with PCMCIA release 2.0 for compatibility with the latest mobile PCs. The advanced design of the VDC-400 draws less than 2 watts of power from the PC, requiring no external power supply or additional batteries. A standard cable is included to connect to most DCE devices, and cables are available for other interfaces. |
|
Specifications (Specifications subject to change without notice.)
| General Characteristics | Physical Characteristics |
| Operating Modes | Half-duplex,full-duplex, simplex |
Dimensions | PCMCIA type II form factor |
| Channel Rate | Up to 16 kbps | Weight | 5 oz |
| Channel Types | SATCOM, LOS, HF, wireline | Volume | 1 cubic in. |
| Network Size | Up to 64 users per channel | Power | |
| Message Connectivity |
Point-to-point,multicast, broadcast |
DC Input Voltage | 5 Vdc (supplied by host) |
| Channel Access | CSMA or Instant-On | Power Dissipation | 200-250 mA (approximate) |
| Compatible COMSEC Devices | AN-CSZ-1A,KY-57/58, ANDVT Tacterm, KY-99/99A/100,KG-84 A/C, KIV-7, STU-III |
Environmental |
|
| Temperature | 0o C to 50o C (operating) -30o C to 50o C (non-operating) |
||
| Cables | KY-57, KY-58, KY-99/A KY-100,KG-84A, KG-84C, STU-III | ||
| Data Interface | PCMCIA | ||
| COMSEC Interface | MIL-188-114 and RS-232 compatible 2400 bps -16 kbps, sync | ||
| OS/hardware supported | WIN 3.X, WIN95 with a type II PCMCIA slot (WIN NT planned upgrade) | ||
|
