Features:
|
high efficiency. |
|
framework of fastness and stabilization
to the antenna can bear the survival wind speed of 55m/s. |
|
favorable withstanding erosion and rust
capability as full-aluminum materials to be used above the
antenna's hub except radials and the coat of all of steel
parts to be processed by heating soak zinc. |
|
every parts have highly processed precision
and no need marks on the parts when installing, it will
not bring to reduce the precision for whole of antenna when
installing repeated. |
|
especially noted for extremely convenient
to install it, easy and fast to aim it at the satellite. |
Type Approvals and Compliances:
APSTAR
ASIASAT
CHINASAT
CHINA ORIENTSAT
SINOSAT
INTELSAT F-1 compliant
ITU-R, S.580-5 and S.465-5
ST-1 compliant
There are three kinds of different standard that can be selected
by users:
SM-T4.5RC for C-Band
SM-T4.5RC/E for Extended C-Band
SM-T4.5RK for Ku-Band
Antenna's main parts:
reflector ----- 12 pieces, made of alloy-aluminum,
painting white color.
radial ----- 12 pieces, alloy-aluminum, anodized
coat.
hub ----- aluminum casting, anodized coat.
pedestal ----- steel, surface processed by
heating soak zinc.
OMT ----- aluminum casting, anodized coat,
with transmit reject filter.
feed-horn ----- ripple type, aluminum casting,
anodized coat.
adjust mode ----- manual, self-existent EL
axis and AZ axis to be adjusted with EL leading screw and AZ
leading screw.
Options:
Non-penetrating mount
Mounting kits for ODU
Motor drive system
Withstand-wind support
Circular polarized
Complete feed component for Tx/Rx:
OMT
Reject transmit filter
Waveguide to coaxial adapter with N type connector (F) |
