SPECIFICATIONS |
C-RECEIVE |
C-TRANSMIT |
Ku-RECEIVE |
Ku-TRANSMIT |
Frequency (GHz) |
3.625-4.2 |
5.85-6.425 |
10.95-12.75 |
13.75-14.5 |
Typical Gain (dBi) |
45.16 |
48.74 |
54.46 |
55.77 |
VSWR |
1.25:1 |
Beamwidth: -3dB |
0.9067° |
0.6° |
0.311° |
0.267° |
-15dB |
|
1.201° |
0.622° |
0.534° |
Antenna Noise Temperature(°K) |
2Port Feed |
|
2/4Port Feed |
|
10°Elevation |
37 |
|
62/68 |
|
20°Elevation |
29 |
|
53/59 |
|
40°Elevation |
23 |
|
44/49 |
|
Power Handing Capability |
|
5KW/Port |
|
1KW/Port |
Feed interface |
CPR-229G |
CPR-137G |
WR-75 |
WR-75 |
Feed Insertion Loss |
0.25dB |
0.2dB |
0.25dB |
0.25dB |
TX - RX |
≥85dB |
≥85dB |
Cross Polarization Isolation (on axis) |
≥35dB |
≥35dB |
Sidelobes |
CCIR.580-4 |
MECHANICAL SPECIFICATIONS |
|
Azimuth Travel |
±65° |
Elevation Travel |
0°to 90 |
Elevation/Azimuth Axis Drive Rates |
0.01°/S-0.03°/S |
Polarization Travel Rate |
Manual±45° , Motor±20° |
Surface Accuracy |
0.5mm(R.M.S) |
ENVIRONMENTAL SPECIFICATIONS |
|
Operational Winds |
45mi/h(72km/h) gusts to 60mi/h(97km/h) |
Survival Winds |
125mi/h(200km/h) |
Ambient Temperature |
-40° to 50° |
Relative humidity |
10- 100% |
Seismic (Survival) |
0.3G ‘ s horizontal 0.15G ‘ s vertical |
